ステンレス鋼製計装用クイック・コネクツ・ボディ、1.5 Cv、12 mmサイズSwagelokチューブ継手
Réf. pièce : SS-QC8-B-12M0
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Spécifications
CorpsRéalisez rapidement et simplement des raccordements, avec les raccords rapides Swagelok, dans des applications qui nécessitent d'effectuer de fréquents raccordements tout en limitant les inclusions d'air et les déversements de fluide. Ouvrir une session ou s’inscrire pour afficher des prix ContactoSi tiene preguntas sobre este producto, contacte con su centro local autorizado de ventas y servicio. También pueden informarle sobre los servicios de apoyo para ayudarle a sacar el máximo partido a su inversión.
Selección fiable de un producto:
El diseñador y usuario del sistema deben revisar la documentación técnica para asegurar una correcta selección de producto. Al seleccionar un producto, habrá que tener en cuenta el diseño global del sistema para conseguir un servicio seguro y sin problemas. El diseñador de la instalación y el usuario son los responsables de la función del componente, de la compatibilidad de los materiales, de los rangos de operación apropiados, así como de la operación y mantenimiento del mismo. Attention: Swagelok-Produkte oder -Bauteile, die nicht den industriellen Entwicklungsnormen entsprechen, einschließlich Swagelok Rohrverschraubungen und Endanschlüsse nicht durch die anderer Hersteller austauschen oder mit den Produkten oder Bauteilen anderer Hersteller vermischen. |
El diseñador y usuario del sistema deben revisar la documentación técnica para asegurar una correcta selección de producto. Al seleccionar un producto, habrá que tener en cuenta el diseño global del sistema para conseguir un servicio seguro y sin problemas. El diseñador de la instalación y el usuario son los responsables de la función del componente, de la compatibilidad de los materiales, de los rangos de operación apropiados, así como de la operación y mantenimiento del mismo.
Attention: Swagelok-Produkte oder -Bauteile, die nicht den industriellen Entwicklungsnormen entsprechen, einschließlich Swagelok Rohrverschraubungen und Endanschlüsse nicht durch die anderer Hersteller austauschen oder mit den Produkten oder Bauteilen anderer Hersteller vermischen.
ステンレス鋼製計装用クイック・コネクツ・ボディ、1.5 Cv、12 mmサイズSwagelokチューブ継手
Ouvrir une session ou s’inscrire pour afficher des prix
Catalogues
Corps
Не требуют закручивания, вращения или использования гаечного ключа; Модели с односторонним и двухсторонним отсечением, и полнопроходные модели
Features: Step-by-step identification procedure for threads and end connections.
Warning: System pressure must not exceed 250 psig (17.2 bar) at 70°F (20°C) when coupling and uncoupling this product. When uncoupling single-end shutoff quick-connects, system pressure on stem side will vent to atmosphere.
Spécifications
SS-QC8-B-12M0 — ステンレス鋼製計装用クイック・コネクツ・ボディ、1.5 Cv、12 mmサイズSwagelokチューブ継手
| Attribut | Valeur |
|---|---|
| Inclusion d'air | 3 cm3 |
| Matériau du corps | Edelstahl 316 |
| Procédé de nettoyage | Standardreinigung und -verpackung (SC-10) |
| Dimension du raccordement 1 | 12 mm |
| Type du raccordement 1 | Swagelok® Rohrverschraubung |
| Cv maximal | 1,5 - bei Verbindung mit einem DESO-Stecker, 2,4 - bei Verbindung mit einem SESO-Stecker |
| Lubrifiant | Dow Corning 111 |
| Matériau des joints toriques | Fluorkautschuk FPM |
| Pression nominale, accouplé, à la temp. max. | 17,2 BAR bei 204 °C /250 PSIG bei 400 °F |
| Pression nominale, accouplé, à temp. amb. | 51,6 BAR bei 21 °C /750 PSIG bei 70 °F |
| Pression nominale, désaccouplé, à temp. amb. | 17,2 BAR bei 21 °C /250 PSIG bei 70 °F |
| Pression/Temp. nominale (accouplement et désaccouplement) | 17,2 BAR bei 21 °C /250 PSIG bei 70 °F |
| Série | QC8 |
| Déversement | 3 cm3 |
| Tests | 3 cm3 |
| eClass (4.1) | 37110302 |
| eClass (5.1.4) | 37110302 |
| eClass (6.0) | 37020500 |
| eClass (6.1) | 37020500 |
| eClass (10.1) | 37020500 |
| UNSPSC (4.03) | 31163101 |
| UNSPSC (10.0) | 27121701 |
| UNSPSC (11.0501) | 27121701 |
| UNSPSC (13.0601) | 27121701 |
| UNSPSC (15.1) | 27121701 |
| UNSPSC (17.1001) | 27121701 |
Ressources
