ステンレス鋼製フル・フロー型クイック・コネクツ・ステム（バルブなし）、23.6 Cv、3/4 インチ・サイズ NPTおねじ
Part #: SS-QF12-S-12PM
|
||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Specifications
ステムメンテナンスが容易で、流れが制限されないSwagelokフル・フロー型クイック・コネクツは、移動／ドレン／ベント・システムに最適です。 Log in or Register to view price ContactIf you have questions about this product, please contact your local authorized sales and service center. They can also tell you about supporting services to help you get the most out of your investment.
Safe Product Selection
The complete catalog contents must be reviewed to ensure that the system designer and user make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user. Warning: スウェージロック製品、または工業設計規格に準拠していない部品（Swagelokチューブ継手エンド・コネクションを含む）は、他社製品との混用や互換は絶対に行わないでください。
|
The complete catalog contents must be reviewed to ensure that the system designer and user make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user.
Warning: スウェージロック製品、または工業設計規格に準拠していない部品（Swagelokチューブ継手エンド・コネクションを含む）は、他社製品との混用や互換は絶対に行わないでください。
ステンレス鋼製フル・フロー型クイック・コネクツ・ステム（バルブなし）、23.6 Cv、3/4 インチ・サイズ NPTおねじ
Log in or Register to view price
Catalogs
ステム
メンテナンスが容易で、流れが制限されないSwagelokフル・フロー型クイック・コネクツは、移動／ドレン／ベント・システムに最適です。
Sin necesidad de torsión, rotación ni de apretado con llaves; Modelos con, cierre sencillo, cierre en la base y en la espiga y de gran caudal
Características: Procedimiento de identificación paso a paso de roscas y conexiones finales.
Págs. 1-2. Procedimientos recomendados para el manejo de los enchufes rápidos Swagelok: Proteja las espigas y las bases con guardapolvos o protectores cuando no estén acopladas. Alinee las bases y las espigas al acoplarlas o desacoplarlas.
Specifications
SS-QF12-S-12PM — ステンレス鋼製フル・フロー型クイック・コネクツ・ステム（バルブなし）、23.6 Cv、3/4 インチ・サイズ NPTおねじ
| Attribute | Value |
|---|---|
| ボディ材質 | 316 ステンレス鋼 |
| 洗浄プロセス | 標準のクリーニングおよびパッケージング（Swagelok SC-10仕様） |
| コネクション1 サイズ | 3/4 インチ |
| コネクション1 タイプ | NPTおねじ |
| 最大Cv | 26.0 - ボディとの接続時 |
| 潤滑剤 | コンポーネントに潤滑剤の塗布なし |
| Oリング材質 | フルオロカーボンFKM |
| 最高使用圧力（最高温度での接続時） | 100 PSIG @ 400°F／6.8 BAR @ 204℃ |
| 最高使用圧力（室温での接続時） | 4000 PSIG @ 70°F／275 BAR @ 21℃ |
| シリーズ | QF12 |
| eClass (4.1) | 37110302 |
| eClass (5.1.4) | 37110302 |
| eClass (6.0) | 37020500 |
| eClass (6.1) | 37020500 |
| eClass (10.1) | 37020500 |
| UNSPSC (4.03) | 31163101 |
| UNSPSC (10.0) | 27121701 |
| UNSPSC (11.0501) | 27121701 |
| UNSPSC (13.0601) | 27121701 |
| UNSPSC (15.1) | 27121701 |
| UNSPSC (17.1001) | 27121701 |
Resources
Drawings
Two-dimensional renderings are available for this product. Download the CAD file.
Three-dimensional renderings are available for this product. Download the CAD file.
Sales drawings are available for this product. Download the files.
