Swagelok® Diaphragm-Sealed Valves
Diaphragm-sealed valves minimize entrapment areas and facilitate purging with a fully swept flow path to improve system efficiency while providing effective flow shutoff. A variety of sizes, materials, and configurations, including atomic layer deposition, thermal immersion, and springless, meet the system requirements of high-purity and ultrahigh-purity applications.
Categories
Diaphragm-Sealed Valves Catalogs
Locate detailed product information, including materials of construction, pressure and temperature ratings, options, and accessories.
Features: Suitable for ultrahigh-purity applications; 316L VIM-VAR stainless steel body; Low-pressure and high-pressure models; VCR®, tube butt weld, and modular surface-mount end connections; Manual or pneumatic actuation
Features: 316L VAR stainless steel body; Working pressures up to 300 psig (20.6 bar); 1/4, 3/8, and 1/2 in.; 10 and 12 mm end connections
Features: 316L stainless steel and modified PTFE wetted parts; Variety of compact multivalve, multiport configurations; Choice of sanitary clamp and butt weld end connections; Choice of pneumatic or manual actuators in plastic or aluminum; Five sizes from 1/2 to 2 in.
Features: Packless, all-metal containment; Working pressures from vacuum to 3500 psig (241 bar); Temperatures from –100 to 250°F (–73 to 121°C)

The Right Valve Can Make All the Difference
Use our valve flow coefficient (Cv) calculator to chose a valve sized correctly for your needs.
Use the ToolSwagelok Resources Curated for You

How to Select the Right Valves for Your Industrial Fluid System
Learn how to apply the practical STAMPED method to select the valves most suited to your industrial fluid or sampling system design applications.

Minimize the Costs of Fugitive Emissions with Low-E Valves
Fugitive emissions are a growing concern in the chemical and petroleum refining industry. Certified low-emissions (Low-E) valves can protect your facility and bottom line. Learn what they are, how they are tested, and how they can help you in this post.

How to Isolate Industrial Fluid Systems with Block Valves
The isolation of industrial fluid system lines prior to maintenance is vital to plant safety. One of the safest ways to isolate a fluid system line is to install two block valves. Learn how to design proper configurations for your system.

One New Valve. Three Reasons It Could Change Semiconductor Manufacturing
Find out how the latest innovation in atomic layer deposition (ALD) valve technology is changing the game for high-tech semiconductor manufacturers.

Diaphragm-Sealed Valves
Our diaphragm-sealed valves are designed in a wide variety of sizes, materials, and configurations to meet the needs of high-purity and ultrahigh-purity (UHP) applications with flow coefficients from 0.20 up to 13 and working pressures up to 3500 psig (241 bar).
Diaphragm-sealed valves provide effective shutoff for your system flow and have a long cycle life. Swagelok’s diaphragm-sealed valve offerings include atomic layer deposition (ALD), springless for high-flow, high-performance, and modular gas systems, thermal-immersion, and ultrahigh-purity fluoropolymer. Manual, pneumatic, and locking actuator options are available.
