스테인리스강 초과 누출 차단 밸브, 1/2인치 스웨즈락 튜브 피팅 |
||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Especificaciones
고정 압력스웨즈락 초과 누출 차단 밸브로 다운스트림 라인 파열 시 유체의 대량 누출을 제어하십시오. 스웨즈락 초과 누출 차단 밸브에는 다운스트림에서 초과 유량이 발생되면 설계된 위치로 이동하고, 압력이 평형을 이루면 다시 제 위치하는 구멍이 가공된 포펫이 있습니다. Inicie la sesión o regístrese para ver los precios ContactIf you have questions about this product, please contact your local authorized sales and service center. They can also tell you about supporting services to help you get the most out of your investment.
Safe Product Selection
The complete catalog contents must be reviewed to ensure that the system designer and user make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user. Advertencia: 스웨즈락의 튜브 피팅 연결구를 포함하여 이러한 제품은 산업 설계 기준에 따라 제조되지 않으므로 스웨즈락의 제품 및 부품을 타 제조업체의 제품 및 부품과 혼합하거나 혼용하여 사용하지 마십시오. |
The complete catalog contents must be reviewed to ensure that the system designer and user make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user.
Advertencia: 스웨즈락의 튜브 피팅 연결구를 포함하여 이러한 제품은 산업 설계 기준에 따라 제조되지 않으므로 스웨즈락의 제품 및 부품을 타 제조업체의 제품 및 부품과 혼합하거나 혼용하여 사용하지 마십시오.
스테인리스강 초과 누출 차단 밸브, 1/2인치 스웨즈락 튜브 피팅
Inicie la sesión o regístrese para ver los precios
Catálogos
고정 압력
스웨즈락 초과 누출 차단 밸브로 다운스트림 라인 파열 시 유체의 대량 누출을 제어하십시오. 스웨즈락 초과 누출 차단 밸브에는 다운스트림에서 초과 유량이 발생되면 설계된 위치로 이동하고, 압력이 평형을 이루면 다시 제 위치하는 구멍이 가공된 포펫이 있습니다.
XS 시리즈 최대 사용압력 6000 psig (413bar), 최대 사용온도 204ºC (400ºF), 1/8 ~ 1/2 in. 및 6 ~ 12 mm 연결구, 스텐레스강 구조
Features: Step-by-step identification procedure for threads and end connections.
Swagelok® Specification SC-10 defines the cleaning, lubrication, assembly, and packaging requirements for standard Swagelok products and describes practices used to meet these requirements.
Valve sizing often is described by the nominal size of the end connections, but a more important measure is the flow that the valve can provide. And determining flow through a valve can be simple.
XS Series Excess Flow Valve Service Instructions
Procedure for installing Swagelok tube fittings in sizes over 1 inch or 25 mm.
Especificaciones
SS-XSS8 — 스테인리스강 초과 누출 차단 밸브, 1/2인치 스웨즈락 튜브 피팅
Atributo | Valor |
---|---|
몸체 재질 | 316 스테인리스강 |
세정 공정 | 표준 세정 및 포장(SC-10) |
연결구 1 크기 | 1/2인치 |
연결구 1 종류 | Swagelok® 튜브 피팅 |
연결구 2 크기 | 1/2인치 |
연결구 2 종류 | Swagelok® 튜브 피팅 |
CV 최대 | 1.1 |
스프링 트립 범위 미국 갤런/분(L/분) | 11.2~14.9(42.3~56.3) |
eClass (4.1) | 37010906 |
eClass (5.1.4) | 37011902 |
eClass (6.0) | 22560307 |
eClass (6.1) | 22560307 |
eClass (10.1) | 22560307 |
UNSPSC (4.03) | 40141601 |
UNSPSC (10.0) | 40141600 |
UNSPSC (11.0501) | 40141600 |
UNSPSC (13.0601) | 40141600 |
UNSPSC (15.1) | 40141600 |
UNSPSC (17.1001) | 40183101 |
Documentación
Planos
Hay disponibles reproducciones bidimensionales para este producto. Descargar el archivo CAD.
Hay disponibles reproducciones tridimensionales para este producto. Descargar el archivo CAD.
Hay planos dimensionales disponibles para este producto. Descargar los archivos
Productos similares
# de Pieza
|
Material del Cuerpo
|
Tamaño conexión 1
|
Tipo de conexión 1
|
Tamaño conexión 2
|
Tipo de conexión 2
|
|
---|---|---|---|---|---|---|
SS-XSF4 | 316 스테인리스강 | 1/4인치 | 암나사 NPT | 1/4인치 | 암나사 NPT | Ver producto |
SS-XSS4 | 316 스테인리스강 | 1/4인치 | Swagelok® 튜브 피팅 | 1/4인치 | Swagelok® 튜브 피팅 | Ver producto |
SS-XSS4-1 | 316 스테인리스강 | 1/4인치 | Swagelok® 튜브 피팅 | 1/4인치 | Swagelok® 튜브 피팅 | Ver producto |
